Overview
1-2 Introduction
Figure 1-1 The Matrix N7 7C107 Chassis with Redundant Power Supplies
➀
Chassis (7C107)
➂
Fan tray (6C407)
➁
Module slots (7 total)
➃
Redundant power supplies (6C207-3) (2)
PS1 PS2
1
45
6
7
23
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS1
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS2
Ã
À
Á
Â
