Introduction 1-1
1
Introduction
This chapter provides an overview of the Matrix N7 chassis and its features. Also covered in this
chapter are the instructions on how to obtain additional help from Enterasys Networks if needed.
1.1 OVERVIEW
The Matrix N7 chassis design provides seven slots for a new advanced generation of modules, the
Matrix DFE series modules. All DFE modules installed in the N7 chassis operate as a system with
a single IP address.
The Matrix N7 chassis
• uses a distributed switching architecture,
• allows hot swapping of the DFE modules,
• supports redundant power supplies, and
• can be installed as a freestanding unit or installed into a standard
48.26-centimeter (19-inch) rack.
All chassis components (power supplies, fan tray, and modules) are installed from the front of the
chassis for ease of maintenance. All LED indicators are observable from the front of the chassis to
aid in monitoring network operational status and performing maintenance. Figure 1-1 illustrates
the Matrix N7 chassis equipped with two 1600-Watt, 6C207-3 redundant power supplies.
