Configuration Guidelines
2-2 Installation Requirements and Guidelines
• Ambient temperature at the installation site must be maintained between 5° and 40°C
(41° to 104°F). Temperature changes must be maintained within 10°C (18°F) per hour.
2.2 CONFIGURATION GUIDELINES
The Matrix N7 chassis has seven slots that accept DFE modules. The slots are numbered 1 to 7
beginning with the leftmost slot. There are two slots near the bottom of the chassis that are strictly
for power supplies. These slots are labeled PS1 and PS2.
The DFE modules for the Matrix N7 chassis are equipped with a firmware-based management
tool, which provides the capability to configure one or more DFE modules; and access chassis,
power supply, and fan tray information.
2.3 LANVIEW LEDs
The following sections describe the LANVIEW LED indications for the following:
• 6C207-3 power supply module
• Fan tray unit
2.3.1 Power Supply LEDs
There are two LEDs on the power supply. Refer to Figure 2-1 for the location of the power supply
LEDs. Table 2-1 describes the different states of the power supply LEDs under six different
conditions. The power supplies are installed in chassis slots PS1 and PS2 in the front-bottom part
of the chassis.
