Specifications and Regulatory Compliance A-1
A
Specifications and Regulatory Compliance
This appendix provides operating specifications for the Matrix N7 7C107 chassis. Enterasys
Networks reserves the right to change the specifications at any time without notice.
A.1 PHYSICAL SPECIFICATIONS
The physical specifications for the Matrix N7 7C107 chassis, the 6C207-3 power supply module,
and the 6C407 fan tray module are as follows:
7C107 Chassis
6C207-3 Power Supply Modules
6C407 Fan Tray
Dimensions: 77.47 H x 44.04 W x 36.83 D (cm)
30.5 H x 17.34 W x 14.5 D (in.)
Weight (with factory installed fan tray): 23.6 kg (52.0 lb)
MTBF (Predicted): 404,872 hours
Dimensions: 12.7 H x 21.0 W x 27.94 D (cm)
5.0 H x 8.27 W x 11.0 D (in.)
Weight: 9.1 kg (20.0 lb)
MTBF (Predicted): 200,000 hours
Dimensions: 6.57 H x 43.64 W x 34.82 D (cm)
2.59 H x 17.18 W x 13.71 D (in.)
Weight: 2.3 kg (5.0 lb)
MTBF (Predicted): 404,787 hours
