Removing and Reinstalling the Fan Tray
Matrix N7 Chassis Setup 3-17
Figure 3-11 Reinstalling the Fan Tray
Once the tray is in place, tighten the two slotted screws ➀ to secure the tray to the Matrix N7
chassis.
➀
Slotted screw (2)
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS1
50/60Hz
LINE 2:
100-125V~12A
200-240V~6A
50/60Hz
LINE 1:
100-125V~10A
200-240V~5A
POWER FAN
PS2
À À
