Application Examples
2-3
2
Network Aggregation Plan
With 24 parallel bridging ports (i.e., 24 distinct collision domains), the V2H124-24
can collapse a complex network down into a single efficient bridged node, increasing
overall bandwidth and throughput.
In the figure below, the 10BASE-T/100BASE-TX ports on the switch are providing
100 Mbps connectivity for up to 24 segments. In addition, the switch is also
connecting several servers at 1000 Mbps.
Figure 2-2. Network Aggregation Plan
Server Farm
10/100 Mbps Segments
...
...
