Enthermics DC400 - Page 26

SPECIFICATIONS
Blanket Warmer ▪ Oper a tor’s Ma nu al ▪ M N- 39 9 2 4 ▪ Rev 4 ▪ 8/20
26
EC750/PT shown with standard Feet
EC-DIM-004349
12.2 " (309mm)
IEC Cord Inlet
Cord length:
6 ft (1.83m) (est.)
23.5" (597mm)
70.0" (1779mm)
23.5" (597mm)
70.0" (1779mm)
32.0" (814mm)
35.5" (900mm)
21.0" (533mm)
CAVITY
19.9" (506mm)
INSERT
21.75" (552mm)
CAVITY
27.1" (688mm)
24.4" (619mm)
28.25" (718mm)
CAVITY
13.1" (333mm)
INSERT
13.2" (336mm)
INSERT
