Entrematic Ditec EL21 User Manual

30
IP1951EN - 2014-10-06
7. Adjustments
i
Make adjustments as explained in the MD1 display module installation manual
7.1 Dip-switches
DIPs Description
OFF
ON
DIP1 Block type VALLOKB No block
DIP2 FUTURE USE / /
DIP3 Door wing weight <200 kg >200 kg
DIP4 FUTURE USE / /
7.2 Signals
LED On Flashing light
POWER Power supply on. Encoder not working or automa-
tion faulty.
SA Indicates that at least one of the safety con-
tacts is open.
Safety test failure (terminal 41).
IN A total or partial opening command or clos-
ing command is received.
The dip switch or COMKR selector status
changes
SETTINGS RESET in pro-SETTINGS RESET in pro-
gress.
BUZZER Event Effect
Escape route test 1 acoustic signal every second
Alarm signalling 5 acoustic signals every minute
COMER selector enabled
6 acoustic signals every 10 seconds
