LED status display indicates operational status
white
PRO Mk2 is powered on and idle
green
DMX1 send or receive (DMX Port 1)
yellow
DMX2 send or receive (DMX Port 2)
blue
standalone mode (show playback)
purple
Midi in or out
red
error
LED will blink between the mentioned colors to signify the status of PRO Mk2
re plug the usb cable if PRO Mk2 is in error state (red) to reset it
USB 2.0
Micro USB connector for connection to computer.
DMX Breakout
DB15 connector To connect the DB15 DMX breakout cable. Compatible with both DMX
only and DMX + MIDI breakout cables.
Only ENTTEC supplied or sold cables should be used for DMX or MIDI Breakout.
