JOHNSON CONTROLS
19
FORM ET130.13-NOM3 (708)
IN-WARRANTY RETURN PROCEDURE
Refer to ENVIRO -TEC Warranty Parts Policy at www.enviro-tec.com.
SERIES FLOW TERMINAL UNIT WEIGHTS -TABLE 4
CFR (22 GA)
BASE UNIT WEIGHT ADDERS TO BASE UNIT WEIGHT
SIZE
SINGLE
WALL
DOUBLE
WALL
WATER COIL
ELEC.
HEAT
1 ROW 2 ROW 3 ROW 4 ROW
0506 58 13 5 7 10 13 20
0606 57 13 5 7 10 13 20
080658135 7101320
061159135 7101320
081160145 7101320
101161145 7101320
0818 75 16 7 11 16 22 23
1018 77 17 7 11 16 22 23
1218 79 17 7 11 16 22 23
1021 79 17 9 11 16 22 23
1221 81 18 9 11 16 22 23
1421 83 18 9 11 16 22 23
1224 108 24 11 23 34 45 27
1424 111 24 11 23 34 45 27
1230 174 38 21 42 63 84 42
1430 177 39 21 42 63 84 42
1630179392142638442
1440 181 40 21 42 63 84 42
1640 184 40 21 42 63 84 42
1644194422142638452
1844 209 46 21 42 63 84 52
