Enviro CFR Installation Operation & Maintenance

JOHNSON CONTROLS
20
FORM ET130.13-NOM3 (708)
PARALLEL FLOW TERMINAL UNIT WEIGHTS - TABLE 5
VFR (22 GA)
BASE UNIT WEIGHT ADDERS TO BASE UNIT WEIGHT
SIZE
SINGLE
WALL
DOUBLE
WALL
WATER COIL
ELECTRIC
HEAT
1 ROW 2 ROW 3 ROW 4 ROW
444
PENDING
10 14 18 22 18
5 44 1014182218
6 46 1014182218
8 48 1014182220
10 85 14 19 25 30 27
12 87 14 19 25 30 31
14118 1621293426
16120 1621293431
REPLACEMENT PARTS LIST
SERIES FLOW TERMINALS
MOTORS AND BLOWERS, MODEL CFR
SIZE H/P
MOTOR
BLOWER
SIZE
PART NO.
120 208/230 277
XX04 1/12 PM-02-1412 PM-02-1413 PM-02-1414 5.75-7 PM-06-0005
XX06 1/6 PM-02-0026 PM-02-0030 PM-02-0032 9-4T PM-06-0119
XX11 1/4 PM-02-0046 PM-02-0051 PM-02-0052 9-7T PM-06-0122
XX18 1/2 PM-02-0068 PM-02-0072 PM-02-0076 9-9R PM-06-0124
XX21 3/4 PM-02-0098 PM-02-0104 PM-02-0106 10-10T PM-06-0135
XX24 1 PM-02-0124 PM-02-0126 PM-02-0128 10-9R PM-06-0134
XX30 2 @ 1/2 PM-02-0068 PM-02-0072 PM-02-0076 2 @ 9-9R PM-06-0124
XX40 2 @ 3/4 PM-02-0098 PM-02-0104 PM-02-0106 2 @ 10-10T PM-06-0135
XX44 2 @ 1 PM-02-0124 PM-02-0126 PM-02-0128 2 @ 10-9R PM-06-0134
MOTORS AND BLOWERS, MODEL CFRQ
SIZE H/P
MOTOR
BLOWER
SIZE
PART NO.
120 208/230 277
XX06 1/6 PM-02-0026 PM-02-0030 PM-02-0032 9-4T PM-06-0119
XX11 1/4 PM-02-0046 PM-02-0051 PM-02-0052 9-7T PM-06-0122
XX17 1/2 PM-02-0068 PM-02-0072 PM-02-0076 10-8T PM-06-0132
XX19 3/4 PM-02-0098 PM-02-0104 PM-02-0106 10-9T PM-06-0133
XX21 1 PM-02-0124 PM-02-0126 PM-02-0128 10-10T PM-06-0135
XX24 1 PM-02-0124 PM-02-0126 PM-02-0128 10-9R PM-06-0134
XX30 2 @ 1/2 PM-02-0068 PM-02-0072 PM-02-0076 2 @ 9-9R PM-06-0124
