Enviro CFR - Electric Heat; Electric Heater Standard Features; Electric Heater Selection Procedure

JOHNSON CONTROLS
22
FORM ET130.13-NOM3 (708)
MOTORS AND BLOWERS, MODEL VFL
SIZE H/P
MOTOR
BLOWER
PART NO.
120 208/230 277
XX04 1/8 PM-02-0001 PM-02-0003 PM-02-0005 PM-06-00148
XX09 1/4 PM-02-1367 PM-02-1368 PM-02-1369 PM-06-00148
XX15 1/2 PM-02-1376 PM-02-1377 PM-02-1378 PM-06-00150
MAGNETIC CONTACTORS
AMPS # OF POLES
COIL VOLTAGE
24 120 240 277 480
25
1 PE-05-1251 PE-05-1252 PE-05-1256 PE-05-1255 PE-05-1257
2 PE-05-2251 PE-05-2252 PE-05-2256 PE-05-2255 PE-05-2257
3 N/A N/A N/A N/A N/A
30
1 PE-05-1301 PE-05-1302 PE-05-1306 PE-05-1305 PE-05-1307
2 PE-05-2301 PE-05-2302 PE-05-2306 PE-05-2305 PE-05-2307
3 PE-05-3301 PE-05-3302 PE-05-3306 PE-05-3305 N/A
35
1 N/A N/A N/A N/A N/A
2 PE-05-2351 PE-05-2352 PE-05-2356 PE-05-2355 N/A
3 PE-05-3351 PE-05-3352 PE-05-3356 PE-05-3355 N/A
40
1 PE-05-1401 PE-05-1402 PE-05-1406 PE-05-1405 N/A
2 PE-05-2401 PE-05-2402 PE-05-2406 PE-05-2405 N/A
3 PE-05-3401 PE-05-3402 PE-05-3406 PE-05-3405 N/A
50
1 PE-05-1501 N/A PE-05-1506 N/A N/A
2 PE-05-2501 PE-05-2502 PE-05-2506 PE-05-2505 N/A
3 PE-05-3501 PE-05-3502 PE-05-3506 PE-05-3505 N/A
MERCURY CONTACTORS
AMPS # OF POLES
COIL VOLTAGE
24 120 240 277 480
35
1 PE-26-1351 PE-26-1352 PE-26-1356 PE-26-1355 PE-26-1357
2 PE-26-2351 PE-26-2352 PE-26-2356 PE-26-2355 PE-26-2357
3 PE-26-3351 PE-26-3352 PE-26-3356 PE-26-3355 PE-26-3357
50
1 PE-26-1501 PE-26-1502 PE-26-1506 PE-26-1505 PE-26-1507
2 PE-26-2501 PE-26-2502 PE-26-2506 PE-26-2505 PE-26-2507
3 PE-26-3501 PE-26-3502 PE-26-3506 PE-26-3505 PE-26-3507
