Maintenance And Service
buRneR RemoVaL:
The burner may need to be removed for a few reasons, including cleaning under the burner,
converting the unit to a different gas type, or to replace the burner altogether. Proceed only
when the unit has completely cooled down.
1. Remove the glass door as shown in
maIntenanCe anD serVICe - glass Door
remoVal.
2. Carefully remove the log set and embers
as shown in seConDary InstallatIon - log
set InstallatIon.
3. Remove the four log tray screws using a
T20 screwdriver, then remove the log tray.
4. Unscrew the two rear burner screws
using a T20 screwdriver.
5. Unscrew the front center burner bolt
using a 5/32” Allen key.
6. Slide the burner to the left and then lift
up to remove it.
To re-install the burner repeat the steps
above in reverse.
Log Tray
Burner
Figure 21: Burner Removal.
