19
Maintenance And Service
embeR Lights - buLb RepLacement:
The front ember light assembly consists of 5 halogen bulbs. Over time, should one of these bulbs
require replacement follow the steps below for the proper procedure. Proceed only when then
replace has been turned off and has completely cooled down.
Note: Gloves should be worn to avoid
skin contact with halogen bulb. Oil on
the bulb from skin contact will greatly
reduce the life span of the bulb.
1. Using the transmitter, turn off the
ember lights (see page 13)
2. Remove the burner as outlined in
maIntenanCe anD serVICe - burner
remoVal.
3. Remove the light tray by simply lifting
up and out.
4. Replace the burnt out bulb with the
extra bulb supplied with the replace.
5. Use the transmitter to conrm all bulbs
light up.
6. Re-install the light tray and burner.
Light Tray
Halogen Bulb
top Light - buLb RepLacement:
The top light assembly is screwed into the top of rebox, behind the bafe, and consists of a
single halogen bulb behind a glass lens. Over time, dependant on the amount of use, the bulb
may require replacement. Should this occur contact your local dealer for service.
Figure 22: Burner Removal.
