Envirovent MEV 160 User Manual

3
MEV 160 & MEV 300
0345 27 27 810
SHOULD YOU ENCOUNTER ANY PROBLEMS
WITH YOUR UNIT, CALL US ON:
ø125
Spigot packs for
ø125mm rigid duct
or ø90/75mm Fast Track
FRONT COVER
ACCESS AREA
CONTROLS
ACCESS AREA
COVER SCREWS
ACCESS AREA
150
COVER SCREWS
ACCESS AREA
150
150
INTERNAL ACCESS (for cleaning or maintenance)
DIMENSIONS
1. Isolate the unit from the mains power supply.
2. Undo all four screws around the front cover and then use a flat head screwdriver to lift the three
clips along the edge of the unit.
3. Now gently pull the cover away from the unit.
DIAGRAMS

Envirovent MEV 160 Specifications

General

Brand	Envirovent
Model	MEV 160
Category	Fan
Language	English
