55
• Although the NDVR depletes capacity of Event Move File area
in primary SD, the NDVR will overwrite EVENT Movie files
stored in the area. When this case occurs, even if EVENT
occurs the NDVR must not record new EVENT Movie file in
Event Movie File area of primary SD.
• The NDVR is record file names of Accident-Event-Log files to
CSV format.
• The PARK Event file is store in this area with separated folder
name use ‘PARK’
Directory of LOG File Area
• Allocate 1% in primary SD memory and Event Logs and
Sensor Logs will be stored in this area.
• A GPS Log is up to 1MB. If this log file becomes 1MB, the
NDVR should close this log file and open new log file to
record GPS data continuously.
• The NDVR is stores G-Sensor data detected by the NDVR in
20[Hz] as G-Sensor Log by CSV format.
• A G-Sensor Log is up to 1MB. If this log file becomes 1MB,
the NDVR should close this log file and open new log file to
record G-Sensor data continuously.
It is able to customize each file area by setup configuration.
(➤ page 78)"
* If one SD memory was inserted in only Primary SD memory
slot of NDVR then It operates according to the allocation of
Primary SD slot.
* If one SD memory was inserted in only Secondary SD
memory slot of the NDVR then It operates according to the
allocation of Primary SD slot. NORMAL movie file area and
EVENT movie area are prepared in the SD memory."
Primary Memory Area Secondary Memory Area
84%
NORMAL
EMERGENCY
EVENT
LOG
System Margin
10%
1%
5%
NORMAL
System Margin
95%
5%
