21
EN
Technical Data
Delivery scope P1/*P1+
The scope of delivery includes:
• 1 sauna heater
• 1 accessory pack with
1 pc. cable gland
3 pc. self-tapping screws B 4.2 X 9.5
4 pc. particle board screws
*4 pc. adjustable feet (only model P1+)
• 1 set of sauna stones, separately in cloth bag or carton
• Installation and operation guide
Power supply 400 V 3N AC 50 Hz
Power output 9,0 kW 10,5 kW 12,0 kW 15,0 kW
Suitable for sauna cabin size 9 - 14 m³ 11 - 15 m³ 14 - 18 m³ 18 - 25 m³
Min. size air inlet and air outlet 35 x 7 cm 35 x 9 cm
Weight, excl. stones / packaging 25,5 kg
Dimensions H x W x D 61 (*74) x 46 x 84 cm
Stone llung 30 kg (*40 kg)
Power extension required (LSG unit) no yes
Suitable sauna control units
Econ-series, Emotec-series,
EmoStyle-series, EmoTouch-series
Leakage current max. 0,75 mA per kW heating power
Intended use Sauna heater for private and commercial sauna cabins
Fuse control unit in A 3 x 16 A
Fuse LSG in A LSG 09 - 3 x 16 A / LSG 18 - 3 x 25 A
Connection cable main - control unit 5 x 2,5²
connection cable main- LSG LSG 09 - 5 x 2,5² / LSG 18 - 5 x 4²
Connection control unit - heater 5 x 1,5²
Connection LSG - heater 5 x 1,5² / **5 x 2,5² **5 x 4²
Connection control unit - LSG 4 x 1,5²
All cross sections of a line are minimum diameters in mm² (Copper line)
* P1+
**by single-circuit connection to LSG 18
