EPC Inverta Series User Manual

Three Phase Output (DC to AC) Inverter
Users Manual
Ver1.2 PAGE :
7
ENGLISH
1.3 GENERAL FEATURES
INDICATIONS AND ALARMS
Digital Measurements (On LCD Display)
Output Voltages (3 phases)
Output Currents (3 phaes)
Input Voltage
Input Current
Cabinet Temperature
*1
Alarms
Alarm Messages (On LCD Display)
DC Low / High / Too Low
Over Temperature
IGBT / IPM Fault
Memory Error
Earth Leakage
*1
Breaker Open
*1
Fuse Failure
*1
Door Open
*1
Hardware Block
*1
Led Indicaters
Input (DC) OK / Fail
Operation
Common Alarm
COMMUNICATION & REMOTE MONITORING
Serial Communication
RS232 / RS485 Isolated Serial Port (Modbus Communication)
*1
Dry Contact Outputs
2 programable alarm contact output
*1 *2
PHYSICAL FEATURES
Dimensions
Please contact your dealer
Protection Degree
IP20
*3
Operation Temperature
-5°C / + 50°C
*4
Storage Temperature
-20°C / + 50°C
Relative Humidity
0% – 90% (non condensing)
Operation Altitude
2000 meters maximum
*1 Not available in stardart configuration. Only provided as option. ( See Section 6, Options)
*2 4 alarm contact output is available, when RS232/RS485 communication is not used. Please consult your dealer.
*3 Higher protection degress are provided upon request, as optional. Please consult your dealer.
*4 Custom solutions for very low ambient temperatures is possible, by adding termostat controlled heaters. Please
consult your dealer.
1.4 ELECTRICAL & PHYSICAL FEATURES
POWER
Nominal Power
2kVA…200kVA
INPUT
Voltage (DC)
24Vdc / 48Vdc / 110Vdc / 216Vdc / 432Vdc
Input Voltage Tolerance
- 20% / + 20%
OUTPUT
Voltage (AC)
115Vac / 120Vac / 220Vac / 230Vac / 240Vac ± 2% (3 Phase + Neutral)
Frequency
50Hz / 60Hz / 83Hz / 400Hz ± 0.1%
Power Factor
0.8
Total Harmonic Distorsion
< 3% (at lineer load)
Crect Factor
Minimum 2 : 1

EPC Inverta Series Specifications

General

Brand	EPC
Model	Inverta Series
Category	Inverter
Language	English
