Three Phase Output (DC to AC) Inverter
Users Manual
Ver1.2 PAGE :
2. SETUP
2.1 OPENING PACKAGE
When the equipment is delivered to you, first to be examined is a possible damage during transport.
Therefore, examine the equipment carefully. For a possible future use, save the packet and wooden
pad of the product after unpacking.
2.2 CHOOSING PROPER PLACE
1. For a proper ventilation, minimum distance between the rear of the inverter and any nearby
object should me minimum 20 cm.
2. Choose a place with proper temperature and humidity.
3. Do not choose any place which can cause dust and corrosion.
4. The place chosen should not have direct sunshine and shouldnt be near any heating source.
5. Operating the equipment in proper conditions will increase it lifetime.
2.3 ELECTRICAL CONNECTION
All electrical connections of the inverter exist on the back of the front door of the enclosure. All
required connections to connection panel of inverter should be made by EPC service personnel or
by the approval of EPC service personnel.
Before making the connections all power switches, isolators and circuit breakers must be in OFF
position.
Because all systems vary depending on user requirements, power, input and output voltages, no
electrical diagram for input and output connections is privided in this manual. Therefore, the
labeling of input and output terminals of the equipment should be referred.
Ground must be connected to the distribution panel.
CAUTION
Connect and control ground (PE) connection. Definitly, the equipment should’nt be operated
without ground connection.
