6
current for 60 seconds,
or the load amp is 1.5
times of rated current for
5 seconds
Fast
Flashing
Refer to section 5
Battery status indicator(LED1、LED2、LED3、LED4)
Battery LED indicator(The parameters in the table below is for 12VDC
system at 25℃, for 24VDC system ,the parameters is doubled)
Table 4-2
LED1
LED2
LED3
LED4
Battery Status
Slowly
Flashing
×
×
×
Under voltage
Fast
Flashing
×
×
×
Over discharged
Battery LED indicator status during voltage is up
○
○
×
×
12.8V< U
bat
<13.4V
○
○
○
×
13.4V< U
bat
<14.1V
○
○
○
○
14.1V < U
bat
Battery LED indicator status during voltage is down
○
○
○
×
12.8V<U
bat
<13.4V
○
○
×
×
12.4V<U
bat
<12.8V
○
×
×
×
U
bat
<12.4V
“○”LED indicates on “×”LED indicates off “U
bat
”battery voltage
