4 Operation
4.1 Features
 Charging and load status indicator
Table 4-1
Indicator
Indicator
Status
System
Status
Note
Charging
status
indicator
On
Charging
Normal
Fast
Flashing
Over
voltage
Refer to section 5
Load status
indicator
On
Load ON
Normal
OFF
Load OFF
Slowly
Flashing
Overload
When the load amp is
1.25times of rated
Charging status indicator
Load status indicator
LED1
Setting
button
Solar Module
Terminals
Battery
Terminals
Load
Terminals
Mounting
Holes
LED2
LED3
LED4
