Epever MPPT Tracer1206AN User Manual

27
5 Specifications
Electrical Parameters
Parameter
Tracer
1206AN
Tracer
2206AN
Tracer
1210AN
Tracer
2210AN
Tracer
3210AN
Tracer
4210AN
System rated
voltage
12/24VDC

Auto-recognition
Rated charging
current
10A
20A
10A
20A
30A
40A
Rated discharge
current
10A
20A
10A
20A
30A
40A
Controller working
voltage range
8~32V
Max. PV open circuit
voltage
60V

46V

100V

92V

MPPT voltage range
(Battery voltage +2V)～
36V
(Battery voltage +2V)～72V
PV rated charge
power
130W/12V
260W/24V
260W/12V
520W/24V
130W/12V
260W/24V
260W/12V
520W/24V
390W/12V
780W/24V
520W/12V
1040W/24V
Self-consumption
≤12mA
Discharge circuit
voltage drop
≤0.23V
Temperature
compensate
coefficient

-3mV/℃/2V (Default)
Grounding type
Common negative
RS485 port
5VDC/200mA
LCD backlight time
Default:60S, Range:0~999S(0 seconds: the backlight is ON all the time)
 When a lithium battery is used, the system voltage can't be identified automatically.
 At minimum operating environment temperature
 At 25℃ environment temperature
 When a lithium battery is used, the temperature compensation coefficient will be 0 and can't be
changed.
Environmental parameters
Environment
temperature
-25℃~+45℃ (100% loads working)
Storage
temperature
-20℃~+70℃
Relative humidity
< 95% (N.C.)
Enclosure
IP30
