Epever MPPT Tracer1206AN User Manual

16
3.3 Setting
1) Clear the generated energy
Step 1: Press the ENTER button and hold 5s under the PV-generated energy interface, and the value
will be flashing.
Step 2: Press the ENTER button to clear the generated energy.
2) Switch the battery temperature unit
Press the button and hold 5s under the battery temperature interface.
3) Battery type
① Support battery types
1
Battery
Sealed(default)
Gel
Flooded
2
Lithium
battery
LiFePO4(4S/ 8S)
Li(NiCoMn)O2 (3S/6S/7S)
3
User
② Set the battery type via the LCD
Operation:
Step1: Press the SELECT button to browse the battery voltage interface.
Step2: Press and hold the ENTER button until the battery-type interface flashes.
Step3: Press the SELECT button to change the battery type, shown as below:
