11
Switch Node
The inverter can be control by the other equipment through the
switch node. When the switch node is link, it equal to ON/OFF
switch is on. The connection between the switch node and the
ON/OFF switch as follow diagram:
POS(+)
NEG(-)
ON/OFF
Switch
If need to use the switch node, a relay should be used. The rating
current of the relay should not be less than 5A. The cross section of
wire needs 1mm
2
.
