12
Centering cups
For button size Product No�
7,0 mm 87001040
8,0 mm 87000842
9,0 mm 87001047
10,0 mm 87001041
11,0 mm 87000840
12,0 mm 87001042
12,7 mm 87000839
13,0 mm 87001385
14,0 mm 87001043
14,5 mm 87001443
15,0 mm 87001386
16,0 mm 87001387
18,0 mm 87003943
19,0 mm 87003944
Grinding wheels for removing body steel
Spacer
Grinding
wheel
Description Product No�
Grinding wheel 87001530
Spacer 2,0 mm for 10 mm button 87001631
Spacer 2,5 mm for 11 mm button 87001632
Spacer 3,0 mm for 12 mm button 87001633
Spacer 3,5 mm for 13 mm button 87001634
Spacer 4,0 mm for 14 mm button 87001635
For 15 mm button combine 2,0 mm spacer and 2,5 mm spacer.
For 16 mm button combine two 2,5 mm spacers.
Grinding templates for button bits
10.95
10.00
8.00
14.50
8.00
7.00
Min 0,5
12,70
Description Product No.
Spherical
7 – 14,5 87005282
11 – 22 87005284
Ballistic
7 – 14,5 87005283
11 – 22 87005285
Trubbnos
6 – 12 87005287
12,1 – 19,1 87005288
Diamond-grain wheels
Spherical Ballistic
Dimension, mm Product No�
Spherical
7 87004554
8 87004555
9 87003969
10 87003970
11 87003971
12 87003972
13 87003973
14 87001025
15 87001384
16 87001027
18 87003964
19 87003966
Ballistic
7 87004556
8 87004557
9 87003974
10 87003975
11 87003976
12 87003977
13 87003413
14 87003414
15 87003415
16 87003416
18 87003965
19 87003967
Trubbnos
8 87004589
10 87004590
11 87004591
12 87004592
12,7 87004593
14,5 87004594
15,8 87004595
19,1 87004596
