pg.5
EA-AMP-70 Installation and Users Manual
1. GLOBAL INPUT
Easily amplify outputs from any stereo source across any/all channels
2. LOOP OUT
Allows global inputs to be sent to other ampliers
3. GAIN CONTROL
Allows independent gain for each pair of inputs
4. BRIDGED SWITCH
Easily couple two channels together for increased power
NOTE: 8-ohm minimum when using bridge mode
5. LINE INPUTS
Individual channel inputs for use with multi-channel preamps/ or dedicated sources
REAR PANEL FEATURES (12D and 8D)
EA-AMP-12D-70
1 2 3 4 5 6 7 8 9 10 11 12
