EPOS Odysse - Page 46

46
Connector Function
CN1 COM5 for Touch
CN3 Single Channel LCD Interface
CN6 Inverter Power
CN10 IDE ACT LED
CN11 Power Switch
CN12 15” POS Card Reader CONN
CN13 USB6
CN14 USB5
CN19 USB3, USB4
CN20 I-Button
CN21 Hardware Reset
CN22 XC9536 Modify Port
CN24 Power LED CONN
CN25 Dual Channel LCD Interface
CN30 Speaker
CN31 MIC & Line-in
