14
1. When charging the battery, connect the charger's power cable to the positive and
negative terminals of the battery. The positive terminal of the charger's power
cable is connected with the positive terminal of the battery, and the negative
terminal of the charger's power cable is connected with the negative terminal of
the battery. Then connect the communication cable from the charger to the battery
CAN-OUT port. Make sure that the connection is correct.
2. After confirming that the battery is turned off, connect the charger to AC power,
and then press the power button on the battery/remote switch to turn on the
battery. If the system has no alarms, indicating that the battery is successfully
charging.
3. After the charging is completed, long press the power button on the battery/
remote switch, then unplug the power plug of the charger, and then release the
connection with the battery charger.
Figure 2-4
Charger
Communication
cable
