2.4 LED Indicator
E-Series Battery has six LEDs on the display panel: a running indicator, an alarming
indicator, four battery level indicators.
Battery
Condition
Description
Battery level
(L-H)
ALM RUN
Shutdown Off
Charging
0%-25% battery level

●
26%-50% battery level
●

●
51%-75% battery level
● ●

●
76%-99% battery level
● ● ●

●
100% battery level
● ● ● ● ●
Overvoltage protection
● ● ● ● ● ●
Over temperature protection
● ● ●
Discharging
76%-100% battery level
● ● ● ● ●
51%-75% battery level
● ● ● ●
26%-50% battery level
● ● ●
1%-25% battery level
● ●
0% battery level
●
Undervoltage protection
● ●
Overcurrent protection
● ● ● ●
Over temperature protection
● ● ●
Others
● ● ● ●
Notes:
●
refers to steady light,

refers to flashing light with flashing frequency of
1Hz.
