7
1.3 Specifications
E40/E80/E175 Battery
Type of battery Lithium iron phosphate battery
Nominal capacity 40Ah(E40) / 80Ah(E80) / 175Ah(E175)
Rated voltage 51.2V
Rated power 2048Wh(E40) / 4096Wh(E80) / 8960Wh(E175)
Charging voltage 57.6V
Discharging cut-off voltage 41.6V
Maximum charging current 20A(E40) / 40A(E80) / 80A(E175)
Maximum continuous
discharging current
40A(E40) / 80A(E80) / 150A(E175)
Parallel connection Max 16 E-Series Batteries
Series connection Not support
Storage temperature -20~60°C
Charging temperature 0~55°C
Discharging temperature -10~55°C
Dimensions (w handle)
420*390*207mm(E40)
555*440*212mm(E80)
500*565*277mm(E175)
Weight
29kg(E40)
49kg(E80)
87kg(E175)
Ingress protection rating IP67
Recommended battery level
during storage
45%~50%
