Epson Aculaser c9100 - Page 13

6 Installing Consumables
6. Make sure the two u marks on the printer match those
of the photoconductor unit, and then remove the tape
from the photoconductor unit.
7. Pull out the protective sheet horizontally.
8. Gently Insert the intermediate transfer unit until it stops.
