Epson BrightLink 455Wi User Manual

Using the Projector on a Network 105
Using Quick Wireless Connection
Using the optional Quick Wireless Connection USB key, you can
connect the projector to a Windows computer wirelessly without any
configuration.
First, make sure you have installed the wireless module as described on
page 103 and turned on the projector.
1. Connect the USB key to the projector’s
TypeA (flat) USB
port.
2. When you see a projected message that the network information
update is complete, remove the USB key.
3. Connect the USB key to a USB port on your computer or
notebook.
In Windows 7 or Windows Vista, if you see the AutoPlay
window, select
Run LaunchU3.exe. When you see the User
Account Control screen, click
Allow.
4. Follow the instructions on the screen to install the Quick Wireless
Connection driver.
If you see a Windows Firewall message, click
Yes to disable the
firewall.
After a few moments, your computer image will be displayed
through the projector. If not, try restarting your computer.
5. When you’re done with your presentation, remove the USB key.
You may need to restart your computer to reactivate your wireless
interface.
Configuring Basic Settings
You can give your projector a unique name, enable a projector
keyword, or create a password for controlling the projector over the
Web.
1. Press the
Menu button, then choose Network and press Enter.
2. Choose
Network Configuration and press Enter.
note
Do not attempt to write to
the USB key or use it as a
flash memory drive.
note
The Quick Wireless
Connection utility will
disable any other wireless
sessions and adapter
programs. Make sure you
leave the USB key in your
computer for your entire
Quick Wireless Connection
session.

Epson BrightLink 455Wi Specifications

Projection

white light output	2500 lumens
color light output	2500 lumens
native resolution	1280 x 800 (WXGA)
throw ratio range (16:10)	0.37 – 0.50
throw ratio range (4:3)	0.44 – 0.59
throw ratio range (16:9)	0.37 – 0.50

Lamp Specifications

lamp type	E-TORL 230 W UHE
lamp life (ECO mode)	up to 3500 hours
lamp life (normal mode)	up to 2500 hours

Power

power supply voltage	100 – 240 V ±10%, 50/60 Hz
power consumption	363 W
network on standby power	10 W
network off standby power	0.3 W

Operating Environment

operating temperature	41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
fan noise (normal mode)	35 dB
fan noise (ECO mode)	28 dB

Weight and Dimensions

dimensions	14.5" x 19.0" x 6.1" (W x D x H)
weight with slide plate	14.1 lb
weight without slide plate	12.9 lb
