Table A-6. Connector Pin Assignments — CN5
Pin I/O Name Description
1 O PFA PF motor drive phase A
2 O PF-/A PF motor drive phase /A
3 O PF-B PF motor drive phase B
4 O PF-/B PF motor drive phase /B
Table A-7. Connector Pin Assignments — CN6
Pin I/O Name Description
1.5 I +42VDC Power voltage supply from power supply board
2.4 — GND Ground
3 I +5VDC Logic voltage suupply from power supply board
Table A-8. Connector Pin Assignments — CN7
Pin I/O Name Description
1 I PE Paper in/out state detection signal
2 — GND Ground
Table A-9. Connector Pin Assignments — CN8
Pin I/O Name Description
1 I HP Home position detection signal
2 — GND Ground
3 O HPV +5VDC
Table A-10. Connector Pin Assignments — CN9
Pin I/O Name Description
1 I ASF Auto sheet Feed sensor
2 — GND Ground
