When the projector is moved, it displays a screen for adjustment and then
automatically corrects the projected image.
You can use Auto H/V-Keystone to correct the projected image under the
following conditions.
• Correction angle: approx. 20˚ right and left/approx. 30˚ up and down
a
• Auto H/V-Keystone only works when Projection is set to Front
from the Configuration menu.
s Extended - Projection p.84
• If you do not want to use the Auto H/V-Keystone function, set Auto
H/V-Keystone to Off.
s Settings - Keystone - H/V-Keystone - Auto H/V-Keystone
p.82
Correcting automatically - Auto V-Keystone - (EB-1771W/
EB-1761W/EB-1751 only)
When using EB-1771W/EB-1761W/EB-1751, only the vertical direction is
corrected automatically. If you need to correct the horizontal direction, use
manual H/V-Keystone.
You can use Auto V-Keystone to correct the projected image under the
following conditions.
• Correction angle: approx. 30˚ up and down
Correcting manually - manual H/V-Keystone -
Manually correct distortion in the horizontal and vertical directions
independently. H/V-Keystone correction is ideal for fine-tuning keystone
distortion.
You can use H/V-Keystone to correct the projected image under the
following conditions.
• Correction angle: approx 30˚ right and left/approx. 45˚ up and down
Correcting keystone distortion in vertical directions
Press the [ ][ ] buttons on the control panel.
Correcting keystone distortion in horizontal directions
Press the [ ][ ] buttons on the control panel.
Adjusting Projected Images
38
