Epson EB-685W User Manual

Projector Parts and Functions
12
The following sections explain the projector parts and their functions.
All of the features in this guide are explained using illustrations of EB-695Wi
unless otherwise mentioned.
gg Related Links
• "Projector Parts - Front/Side" p.12
• "Projector Parts - Top/Side" p.13
• "Projector Parts - Interface" p.14
• "Projector Parts - Base" p.16
• "Projector Parts - Control Panel" p.16
• "Projector Parts - Remote Control" p.17
• "Projector Parts - Interactive Pens" p.19
• "Projector Parts - Pen Tray" p.20
• "Projector Parts - Touch Unit" p.20
Projector Parts - Front/Side
Name Function
A
Remote receiver Receives signals from the remote control.
B
Lamp cover Open to access the projector's lamp.
C
Lamp cover screw Screw to fix the lamp cover in place.

Epson EB-685W Specifications

General

Projection Technology	3LCD
Native Resolution	WXGA (1280 x 800)
Brightness	3500 lumens
Contrast Ratio	14, 000:1
Lamp Life	Up to 10, 000 hours (ECO mode)
Keystone Correction	Manual vertical: ± 3°, Manual horizontal ± 3°
Connectivity	HDMI, USB, VGA
Zoom	Digital Zoom
Speakers	16W Mono
