Screen Size and Projection Distance
238
4:3 screen size
A B C
Minimum (Wide) to
Maximum (Tele)
Minimum
(Wide)
Minimum
(Wide)
60" 122 × 91 40.3 - 55.0 10.9 102.4
70" 142 × 107 47.3 - 60.1 14.1 120.8
80" 163 × 122 54.3 - 60.1 17.3 139.2
88" 179 × 134 60.1 19.8 153.9
16:9 screen size
A B C
Minimum (Wide) to
Maximum (Tele)
Minimum
(Wide)
Minimum
(Wide)
59" 131 × 74 35.8 - 48.9 13.0 86.5
60" 133 × 75 36.4 - 49.8 13.3 88.1
70" 155 × 87 42.8 - 58.3 16.9 104.1
80" 177 × 100 49.1 - 60.1 20.5 120.1
90" 199 × 112 55.5 - 60.1 24.1 136.1
97" 215 × 121 59.9 - 60.1 26.6 147.4
XGA (EB-680/EB-670)
4:3 screen size
A B C
Minimum (Wide) to
Maximum (Tele)
Minimum
(Wide)
Minimum
(Wide)
56" 114 × 85 35.7 - 48.7 6.5 91.8
60" 122 × 91 38.4 - 52.3 7.5 98.9
70" 142 × 107 45.0 - 60.1 10.1 116.8
80" 163 × 122 51.6 - 60.1 12.7 134.6
90" 183 × 137 58.2 - 60.1 15.3 152.5
92" 187 × 140 59.6 - 60.1 15.8 156.0
16:9 screen size
A B C
Minimum (Wide) to
Maximum (Tele)
Minimum
(Wide)
Minimum
(Wide)
52" 115 × 65 36.1 - 49.3 17.4 82.2
60" 133 × 75 41.9 - 57.1 21.4 96.1
70" 155 × 87 49.1 - 60.1 26.3 113.4
80" 177 × 100 56.4 - 60.1 31.2 130.8
85" 188 × 106 60.0 - 60.1 33.6 139.5
