Projector Parts and Functions
12
The following sections explain the projector parts and their functions.
gg Related Links
• "Projector Parts - Front/Side" p.12
• "Projector Parts - Top/Side" p.13
• "Projector Parts - Interface" p.14
• "Projector Parts - Base" p.16
• "Projector Parts - Control Panel" p.16
• "Projector Parts - Remote Control" p.17
• "Projector Parts - Interactive Pens" p.19
• "Projector Parts - Pen Tray" p.20
• "Projector Parts - Touch Unit" p.20
Projector Parts - Front/Side
Name Function
A
Remote receiver Receives signals from the remote control.
B
Indicators Indicates the projector's status.
C
Speaker Outputs audio.
D
Lamp cover Open to access the projector's lamp.
E
Lamp cover screw Screw to fix the lamp cover in place.
