Screen Size and Projection Distance
236
Check the table here to determine how far to place the projector from the
screen based on the size of the projected image.
A
Projection distance (cm)
B
Distance from the projector to the top of the screen (when mounting on a wall
or ceiling, or installing vertically) (cm)
Distance from the projector to the bottom of the screen (when placing on a
surface such as a desk) (cm)
C
Distance from the projector to the bottom of the screen (when mounting on a
wall or ceiling, or installing vertically) (cm)
Distance from the projector to the top of the screen (when placing on a surface
such as a desk) (cm)
D
Distance from the center of the lens to the rear of the projector (cm)
16:10 screen size
A B C
Minimum (Wide) to
Maximum (Tele)
Minimum
(Wide)
Minimum
(Wide)
70" 151 × 94 40.5 - 55.8 12.9 107.2
80" 172 × 108 46.7 - 64.3 15.7 123.4
90" 194 × 121 53.0 - 72.8 18.6 139.7
100" 215 × 135 59.3* 21.4 156.0
* Project using Wide (maximum zoom).
