Projector Parts and Functions
15
Name Function
E
Audio port Inputs audio from equipment connected to the
Computer port.
From now on, referred to as the Audio 1 port.
F
Mic port Inputs audio from the microphone.
G
Power inlet Connects the power cord to the projector.
H
HDMI1/MHL port Inputs video signals from HDMI compatible video
equipment and computers, or MHL (Mobile High-
Definition) compatible mobile devices.
This projector is compatible with HDCP.
I
HDMI2 port Inputs video signals from HDMI compatible video
equipment and computers.
This projector is compatible with HDCP.
J
HDMI3 port Inputs video signals from HDMI compatible video
equipment and computers.
This projector is compatible with HDCP.
K
LAN port Connects a LAN cable to connect to a network.
L
USB-B port Connects a USB cable to the computer to project
computer images or to use the Wireless Mouse
function.
Connects the projector to a computer via the supplied
USB cable to use the interactive pen as a mouse.
M
USB-A port Connects a USB memory device or a digital camera
and projects movies or images using PC Free. Select
USB1 as the image source when you connect a USB
device to this port to use the projector's PC Free
features.
Connects the optional document camera. Select USB2
as the image source when you connect the document
camera to this port.
Name Function
N
USB-A port Connects a USB memory device or a digital camera
and projects movies or images using PC Free. Select
USB1 as the image source when you connect a USB
device to this port to use the projector's PC Free
features.
Connects the optional document camera. Select USB2
as the image source when you connect the document
camera to this port.
O
Computer port Inputs image signals from a computer and component
video signals from other video sources.
P
TCH port Connects the supplied Touch Unit connection cable to
the Touch Unit.
Q
SYNC IN/OUT port When using the interactive features in the same room
as multiple versions of the same projector, you need to
connect the optional remote control cable set to the
projectors. When the cable set is connected, the
interactive pen operates stably.
R
RS-232C port Connects an RS-232C cable to control the projector
from a computer. (This port is for control use and
should not normally be used.)
S
Wireless LAN module
slot
Install the optional wireless LAN module.
To Next Page
