14
Projector Parts and Functions
Name Function Name Function
C
Rear feet When the projector is set up on a surface such as a
B
[Enter] button [ ] Enters the current selection and moves to the next level
desk, turn to extend and retract the feet to adjust the while displaying the projector's menu or help.
horizontal tilt.
Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
D
Front adjustable foot When the projector is set up on a surface such as a
RGB signal from the Computer port.
desk, extend the foot to adjust the position of the
image. From now on, referred to as the [Enter] button.
C
Keystone adjustment Displays the Keystone screen allowing you to correct
buttons and arrow keystone distortion.
gg Related Links
buttons
Selects menu items while displaying the projector's
• "Installing a Security Cable" p.80
menu or help.
D
[Esc] button Stops the current function.
Projector Parts - Control Panel
Moves back to the previous menu level while
displaying the projector's menu.
E
Volume buttons and
• EB-U32/EB-W32/EB-W31/EB-X36/EB-X31/EB-
arrow buttons
U04/EB-W04/EB-X04/EB-U130/EB-W130/EB-
Wide/Tele buttons
X130/EB-X350/EB-X300:
: Decreases the volume.
: Increases the volume.
• EB-S31/EB-S04/EB-S130/EB-S300:
: Enlarges the size of the projected image.
: Reduces the size of the projected image.
Corrects keystone distortion in the horizontal direction
when the Keystone screen is displayed.
Selects menu items while displaying the projector's
menu or help.
Name Function
F
[Menu] button Displays and closes the projector's menu.
A
[Source Search] Changes to the next input source.
button
G
[Home] button Displays and closes the Home screen.
H
Turns the projector on or off.
Power button [ ]
From now on, referred to as the power button.
I
Indicators Indicates the projector's status.
