Epson EB-X31 User Manual

58
Projecting Two Images Simultaneously
• USB Display, USB and LAN
c
To select an input source for the other image, select the Source setting,
e
To enlarge one image while reducing the other image, select Screen
press [Enter], select the input source, select Execute, and press [Enter]. Size, press [Enter], select a size, press [Enter], and press [Menu] to exit.
Depending on the video input signals, the images may not
appear at the same size even if you select Equal.
a
f
To select the audio, select Audio Source, press [Enter], select an audio
option, press [Enter], and press [Menu] to exit.
Select Auto to hear audio from the largest screen or the left
screen.
a
• You can only select input sources that can be combined.
a
• While using the split screen feature, the source screen appears
when you change the input source from the remote control.
g
To exit the split screen feature, press [Split] or [Esc].
gg Related Links
d
To switch images, select Swap Screens and press [Enter].
• "Unsupported Input Source Combinations for Split Screen Projection" p.58
The projected images on the left and right are swapped.
• "Split Screen Projection Restrictions" p.59
Unsupported Input Source Combinations for Split
Screen Projection
These input source combinations cannot be projected on a split screen.
• Computer, Video and S-Video

Epson EB-X31 Specifications

General

Projection Technology	3LCD
Resolution	XGA (1024 x 768)
Contrast Ratio	15000:1
Lamp Life Normal	5000 hours
Lamp Life ECO	10000 hours
Projection Ratio	1.48 - 1.77:1
Zoom	1.2x
Screen Size	30 inches - 300 inches
Weight	2.4 kg
Brightness	3200 lumens
Keystone Correction	Vertical ±30 degrees, Horizontal ±30 degrees
Inputs	HDMI, VGA, USB 2.0 Type A, USB 2.0 Type B, Composite
Output Ports	VGA
Security	Kensington lock, Password protection
Color Modes	Dynamic, Presentation, Cinema, sRGB, Blackboard
