Epson EB-X39 User Manual

Controlling a Networked Projector Using a Web Browser
108
f
Select the icon corresponding to the projector function you want to
control.
A
Power button control
B
Selects HDMI port source
C
Selects Video source
D
Selects the USB Display source
E
Selects the Screen Mirroring source (EB‑2247U/EB‑2142W)
F
A/V Mute button control
G
Freeze button control
H
Page up and down button controls
I
Displays the QR code
J
Volume button controls
K
Selects the USB device source
L
Selects the network source
M
Selects Computer port source
N
Searches for sources
g
To select projector menu settings, select Advanced on the Epson Web
Control screen.
a
• You can also change projector settings by accessing the
projector menu system from OSD Control Pad. See help on
how to use the OSD Control Pad screen.
• You may need to log in to access some of the options on the
Epson Web Control screen. If you see a log in window, enter
your user name and password. (The user name is EPSONWEB
and the default password is admin.)
• You can change the password in Web Control Password in
the projector's Network menu.
s Network > Network Configuration > Basic > Web
Control Password
h
Select the name of the menu and follow the on-screen instructions to
select settings.

Epson EB-X39 Specifications

General

Resolution	XGA (1024 x 768)
Contrast Ratio	15, 000:1
LCD Panel	0.55 inch with MLA (D10)
Projection Ratio	1.48 - 1.77:1
Lens	Optical
Screen Size	30 inches - 300 inches
3D	No
Brightness	3500 lumens
Lamp Life	12, 000 hours (ECO mode)
Connectivity	HDMI, VGA, USB
Projection System	3LCD
Keystone Correction	Vertical ±30 degrees, Horizontal ±30 degrees
Zoom	1.2x
Interfaces	HDMI in, VGA in, USB Type-A, USB Type-B, Composite in, Audio in
Security	Kensington lock, Password protection
Speakers	2 W
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
