Epson EB-X39 User Manual

Projector Connections
29
c
Connect one end of the cable to your external speakers as necessary.
d
Connect the stereo mini-jack end of the cable to your projector's Audio
Out port.
gg Related Links
• "Projector Setup Settings - ECO Menu" p.144
• "Projector Setup Settings - Extended Menu" p.131
Connecting a Microphone
You can connect a microphone to the projector's Mic port to provide audio
support during presentations
(EB‑2247U/EB‑2142W/EB‑2042/EB‑990U/EB‑980W/EB‑970/EB‑109W/EB‑108
/EB‑107).
If you want to output audio from a microphone when the projector is turned
off, select Always On as the A/V Output setting in the projector's Extended
menu.
s Extended > A/V Settings > A/V Output
a
• If you connect a condenser microphone with plug-in power support,
select On as the Plug-in Power setting in the projector's Extended
menu.
s Extended > A/V Settings > Plug-in Power
• Adjust Mic Input Level if the microphone audio is difficult to hear,
or if it is too loud resulting in a crackling sound.
s Settings > Mic Input Level
a
Connect the microphone cable to the projector's Mic port.
b
Turn on the microphone, if necessary.
gg Related Links
• "Projector Setup Settings - Extended Menu" p.131
• "Projector Feature Settings - Settings Menu" p.129

Epson EB-X39 Specifications

General

Resolution	XGA (1024 x 768)
Contrast Ratio	15, 000:1
LCD Panel	0.55 inch with MLA (D10)
Projection Ratio	1.48 - 1.77:1
Lens	Optical
Screen Size	30 inches - 300 inches
3D	No
Brightness	3500 lumens
Lamp Life	12, 000 hours (ECO mode)
Connectivity	HDMI, VGA, USB
Projection System	3LCD
Keystone Correction	Vertical ±30 degrees, Horizontal ±30 degrees
Zoom	1.2x
Interfaces	HDMI in, VGA in, USB Type-A, USB Type-B, Composite in, Audio in
Security	Kensington lock, Password protection
Speakers	2 W
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
