Epson EB-X39 User Manual

Projector Connections
22
b
Connect the other end to a Computer port on the projector.
c
Tighten the screws on the VGA connector.
d
Connect the audio cable to your laptop's headphone or audio-out jack,
or your desktop's speaker or audio-out port.
e
Connect the other end to the Audio port that corresponds to the
Computer port you are using.
gg Related Links
• "Projector Setup Settings - Extended Menu" p.131
Connecting to a Computer for USB Video and Audio
If your computer meets the system requirements, you can send video and
audio output to the projector through the computer's USB port. This function
is called USB Display. Connect the projector to your computer using a USB
cable.
a
• If you use a USB hub, the connection may not operate correctly.
Connect the USB cable directly to the projector.
a
Connect the cable to your projector's USB-B port.
b
Connect the other end to any available USB port on your computer.
c
Turn on the projector and your computer.
d
Do one of the following to install the Epson USB Display software:
a
You only need to install this software the first time you connect
the projector to the computer.
• Windows: Select Run EMP_UDSE.EXE in the dialog box that is
displayed to install the Epson USB Display software.
• Mac: The Epson USB Display setup folder is displayed on your
screen. Select USB Display Installer and follow the on-screen

Epson EB-X39 Specifications

General

Resolution	XGA (1024 x 768)
Contrast Ratio	15, 000:1
LCD Panel	0.55 inch with MLA (D10)
Projection Ratio	1.48 - 1.77:1
Lens	Optical
Screen Size	30 inches - 300 inches
3D	No
Brightness	3500 lumens
Lamp Life	12, 000 hours (ECO mode)
Connectivity	HDMI, VGA, USB
Projection System	3LCD
Keystone Correction	Vertical ±30 degrees, Horizontal ±30 degrees
Zoom	1.2x
Interfaces	HDMI in, VGA in, USB Type-A, USB Type-B, Composite in, Audio in
Security	Kensington lock, Password protection
Speakers	2 W
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
