Supported Monitor Display Resolutions
189
The tables here list the compatible refresh rate and resolution for each
compatible video display format.
Component Signals (Analog RGB)
For
EB‑2247U/EB‑2142W/EB‑2042/EB‑990U/EB‑980W/EB‑970/EB‑109W/EB‑108/
EB‑107/EB‑W39/EB‑X39
Signal Refresh rate (Hz) Resolution (dots)
VGA 60/72/75/85 640 × 480
SVGA 60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1366 × 768
60/75/85 1280 × 800
WXGA+ 60/75/85 1440 × 900
WXGA++ 60 1600 × 900
SXGA 70/75/85 1152 × 864
60/75/85 1280 × 960
60/75/85 1280 × 1024
SXGA+ 60/75 1400 × 1050
WSXGA+ * 60 1680 × 1050
UXGA 60 1600 × 1200
WUXGA (Reduced
Blanking) **
60 1920 × 1200
* Available only for
EB‑2247U/EB‑2142W/EB‑990U/EB‑980W/EB‑109W/EB‑W39 and compatible
only when Wide is selected as the Resolution setting in the projector's Signal
menu.
** Available only for EB-2247U/EB-990U.
For EB‑S39
Signal Refresh rate (Hz) Resolution (dots)
VGA 60/72/75/85 640 × 480
SVGA 60/72/75/85 800 × 600
XGA 60/70/75/85 1024 × 768
WXGA 60 1280 × 768
60 1366 × 768
60/75 1280 × 800
WXGA+ 60 1440 × 900
SXGA 70/75 1152 × 864
60 1280 × 960
60 1280 × 1024
SXGA+ 60 1400 × 1050
Even when signals other than those mentioned above are input, it is likely that
the image can be projected. However, not all functions may be supported.
Component Video
Signal Refresh rate (Hz) Resolution (dots)
SDTV (480i/480p) 60 720 × 480
SDTV (576i/576p) 50 720 × 576
HDTV (720p) 50/60 1280 × 720
HDTV (1080i/1080p *) 50/60 1920 × 1080
* Available only for
EB‑2247U/EB‑2142W/EB‑2042/EB‑990U/EB‑980W/EB‑970/EB‑109W/EB‑108/
EB‑107/EB‑W39/EB‑X39 and for the input signals from the Computer port.
Composite Video
Signal Refresh rate (Hz) Resolution (dots)
TV (NTSC) 60 720 × 480
