Epson EH-LS500B User Manual

Configuration Menu
61
Function Menu/Settings Explanation
Reset
Yes, No
Resets all Signal settings except for Diagonal
Screen Size, 3D Viewing Notice, and Aspect.
*1
Settings are saved for each type of input source or signal.
*2
You may not be able to make selections depending on the source or type of signal.
Settings menu
Function Menu/Settings Explanation
Installation
Guide
- Displays a guide so that you can adjust the posi-
tion during installation.
Keystone
H/V-Keystone V-Keystone -12 to 12 Corrects keystone distortion. s p.28
•
H/V-Keystone: Manually corrects horizontal and
vertical distortions.
s p.28
•
Quick Corner: Corrects the corners of the pro-
jected image individually.
s p.29
H-Keystone -12 to 12
Quick Corner -
Blanking
Covers part of the image with a blank (black
screen). You can set the top, bottom, left, or right
of the image.
Zoom
Adjusts the size of the image. s p.26
Image Shift
- Adjusts the position of the projected image with-
out having to move the projector.
s p.27
Volume
Adjusts the volume.
HDMI Link
Device Connections - Displays a list of devices connected to the
HDMI1/HDMI2/HDMI3 ports.
HDMI Link On, Off Enables or disables the HDMI Link function.
Audio Out Device Projector, AV Sys-
tem
Selects which device outputs audio.
s p.46
Power On Link Off, Bidirectional,
Device -> PJ, PJ ->
Device
Sets the link function when the power is turned
on.
•
When linking operations to the connected de-
vice and turning on the projector, select Bidir-
ectional or Device -> PJ.
•
When linking power on for the projector to the
connected device, select Bidirectional or PJ ->
Device.
Power Off Link On, Off Sets whether or not to power off connected de-
vices when the projector is turned off.
Link Buffer On, Off If HDMI Link is not working correctly, you may be
able to improve it by changing the settings.

Epson EH-LS500B Specifications

General

Matrix size	0.62 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.4 - 0.82 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 130 \
Projector native resolution	-
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1200 ANSI lumens
Cables included	AC
Smart TV	No
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	230 W
Video color modes	Bright cinema, Cinema, Dynamic, Game
Supported 3D formats	Side by side, Top and bottom
Throw ratio	0.27 - 0.37:1
Fixed focal length	3.9 mm
Focal length range	- mm
Aperture range (F-F)	1.5 - 1.5
Placement	Desktop
Product type	Ultra short throw projector
Product color	Black
Cable lock slot type	Kensington
Light source type	Laser
Service life of light source	20000 h
RMS rated power	10 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	458 mm
Height	228 mm
Weight	9300 g
Package depth	590 mm
Package width	350 mm
Package height	532 mm
Package weight	12.954 g
