Contents

Organization of the Guide and

Notations in the Guide

Using Each Guide ..................... 1

Notations Used in This Guide ........... 2

Safety Indications.......................2

General Information Indications .............2

About the Use of "This Product" or "This Projector"

..................................... 2

Introduction

Projector Features .................... 6

Project Large Images Even when Near a Wall

..................................... 6

Project Images from Mobile Devices ..........6

Other Useful Functions .................... 6

Part Names and Functions ............. 7

Front/Top ............................. 7

Rear/Top .............................. 8

Connector Ports .........................9

Base ................................ 10

Control Panel .......................... 11

Remote Control ........................ 12

Preparing

Installing ............................ 14

Projected Image and Position of Projector.....14

Installing in parallel with the screen ........14

Installing the projector horizontally by

adjusting the height of either side ......... 15

Screen Size and Projection Distance.........16

Connecting a Device ................. 17

Connecting a Streaming Media Player........ 17

Connecting Video Equipment ..............18

Connecting a Computer .................. 19

Connecting to the LAN Port...............19

Attaching the Wireless LAN Unit............19

Connecting External Speakers .............. 20

Connecting an ARC Compatible AV System....20

Preparing the Remote Control ........ 21

Installing the Remote Control Batteries.......21

Remote Control Operating Range ...........21

Operating range (left to right) ............21

Operating range (top to bottom) .......... 21

Basic Operations

Projecting Images ................... 22

Turning On the Projector.................22

If the target image is not projected . . . . . . . . 23

Using the Home Screen .................. 24

Turning Off ...........................25

Adjusting the Projected Image . . . . . . . . 26

Adjusting the Focus ..................... 26

Adjusting the Projection Size (Adjust Zoom)

....................................26

Adjusting the Position of the Image (Image

Shift) ................................ 27

Correcting Vertical Distortion in the Image ..... 27

Correcting Keystone Distortion ............. 28

Correct using the Keystone buttons ........ 28

Correcting with Quick Corner............ 29

Adjusting the Volume .................... 30

Hiding the Image and Muting the Audio

Temporarily (A/V Mute) .................. 30

Adjusting the Image

Adjusting the Image ................. 31

Selecting the Projection Quality (Color Mode)

....................................31

Switching the Screen Between Full and Zoom

(Aspect).............................31

Adjusting the Sharpness .................. 33

Adjusting Image Resolution (Image

Enhancement) ......................... 34

Adjusting the Luminance for Images .........35

Setting Frame Interpolation............... 35

Setting the Image Processing Speed .........36

Adjusting the Color .................. 37

Adjusting the Color Temp.................37

Adjusting the RGB (Offset and Gain).........37

Adjusting Hue, Saturation, and Brightness . . . . . 38

Adjusting the Gamma ...................39

Questions and Answers:

Need help?

Do you have a question about the Epson EH-LS500B and is the answer not in the manual?

Epson EH-LS500B Specifications

General

Matrix size	0.62 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.4 - 0.82 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 130 \
Projector native resolution	-
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1200 ANSI lumens
Cables included	AC
Smart TV	No
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	230 W
Video color modes	Bright cinema, Cinema, Dynamic, Game
Supported 3D formats	Side by side, Top and bottom
Throw ratio	0.27 - 0.37:1
Fixed focal length	3.9 mm
Focal length range	- mm
Aperture range (F-F)	1.5 - 1.5
Placement	Desktop
Product type	Ultra short throw projector
Product color	Black
Cable lock slot type	Kensington
Light source type	Laser
Service life of light source	20000 h
RMS rated power	10 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
Quantity per pack	1 pc(s)
