Epson EH-LS500B User Manual

Basic Operations
24
Using the Home Screen
The Home screen feature allows you to easily select an image source and access useful functions.
Press the [Home] button on the control panel to display the Home screen.
You can also display the Home screen by using the home button on the remote control.
Under the following conditions, the Home screen is displayed automatically when the projector is turned on.
•
Home Screen Auto Disp. is set to On. s Extended - Home Screen - Home Screen Auto Disp. p.63
•
There are no signals from any sources.
a
Selects the source you want to project.
b
Displays the Connection Guide.
c
Displays the Configuration menu. s p.57
d
Performs menu options assigned to Custom Function 1 and Custom Function 2 on the Home Screen.
s Extended - Home Screen p.63
e
Sets the brightness for the light source. s Image - Light Output p.58
f
Selects the Color Mode. s p.31 s Image - Color Mode p.58
c
The Home screen disappears after 10 minutes of inactivity.

Epson EH-LS500B Specifications

General

Matrix size	0.62 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.4 - 0.82 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 130 \
Projector native resolution	-
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1200 ANSI lumens
Cables included	AC
Smart TV	No
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	230 W
Video color modes	Bright cinema, Cinema, Dynamic, Game
Supported 3D formats	Side by side, Top and bottom
Throw ratio	0.27 - 0.37:1
Fixed focal length	3.9 mm
Focal length range	- mm
Aperture range (F-F)	1.5 - 1.5
Placement	Desktop
Product type	Ultra short throw projector
Product color	Black
Cable lock slot type	Kensington
Light source type	Laser
Service life of light source	20000 h
RMS rated power	10 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	458 mm
Height	228 mm
Weight	9300 g
Package depth	590 mm
Package width	350 mm
Package height	532 mm
Package weight	12.954 g
