Epson EH-LS500B User Manual

Contents
4
Select and adjust the correction value . . . . . . 39
Adjust using the gamma adjustment graph
.................................. 40
Viewing the Image at the Saved Image
Quality (Memory Function) . . . . . . . . . . . 41
Saving a Memory .......................41
Loading, Deleting, and Renaming a Memory
.................................... 42
Useful Functions
Enjoying 3D Images .................. 43
Preparing to View 3D Images .............. 43
If the 3D image cannot be viewed .........43
Using 3D Glasses ....................... 44
Warnings Regarding Viewing 3D Images......44
Using the HDMI Link Function ........ 46
HDMI Link Function ..................... 46
HDMI Link Settings ...................... 46
Connecting ........................... 47
Using the Projector on a Network
Projecting Using Wired LAN .......... 48
Selecting Wired Network Settings ...........48
Projecting Using Wireless LAN ........ 50
Selecting Wireless Network Settings Manually
.................................... 50
Selecting the Computer's Wireless LAN Settings
.................................... 53
Selecting wireless network settings in
Windows ........................... 53
Selecting wireless network settings in OS X
.................................. 53
Setting Up Wireless Network Security . . . . . . . . 53
Projecting in Epson iProjection (iOS/Android)
.................................... 54
Operating using a smartphone (remote
control function) .....................55
Configuration Menu
Configuration Menu Functions ........ 57
Configuration Menu Operations ............ 57
Configuration Menu Table................58
Image menu ........................58
Signal menu ........................ 59
Settings menu ....................... 61
Extended menu ...................... 63
Network menu ....................... 65
Info menu .......................... 69
Reset menu ......................... 69
Troubleshooting
Problem Solving . .................... 70
Handling Problems .....................70
Reading the Indicators ................... 70
Indicator status during an error/warning....71
Indicator status during normal operation . . . . 72
When the Indicators Provide No Help........73
Check the problem .................... 73
Problems relating to images ............. 74
Noise problems ...................... 77
Problems when projection starts ..........77
Problems with the remote control ......... 78
Problems with the control panel .......... 78
Problems with 3D .................... 78
Problems with HDMI ..................79
Problems with a streaming media player . . . . 80
Network problems .................... 80
About Event ID ........................ 82
Maintenance
Maintenance ........................ 83
Cleaning the Parts ...................... 83
Cleaning the air filter .................. 83
Cleaning the main unit ................. 85
Cleaning the lens ..................... 85
Replacement Periods for Consumables.......85
Air filter replacement period ............. 85
Replacing Consumables .................. 85
Replacing the air filter .................85
Panel Alignment ..................... 87
Color Uniformity ..................... 89
About PJLink ........................ 91

Epson EH-LS500B Specifications

General

Matrix size	0.62 \
Number of colors	1.073 billion colors
Native aspect ratio	16:9
Projection distance	0.4 - 0.82 m
Projection technology	3LCD
Contrast ratio (typical)	2500000:1
Screen size compatibility	65 - 130 \
Projector native resolution	-
Keystone correction, horizontal	-3 - 3 °
Projector brightness (economic mode)	1200 ANSI lumens
Cables included	AC
Smart TV	No
Ethernet LAN (RJ-45) ports	1
Audio (L/R) in	0
HDMI connector type	Full-size
HDMI ports quantity	3
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	366 W
Power consumption (economy mode)	230 W
Video color modes	Bright cinema, Cinema, Dynamic, Game
Supported 3D formats	Side by side, Top and bottom
Throw ratio	0.27 - 0.37:1
Fixed focal length	3.9 mm
Focal length range	- mm
Aperture range (F-F)	1.5 - 1.5
Placement	Desktop
Product type	Ultra short throw projector
Product color	Black
Cable lock slot type	Kensington
Light source type	Laser
Service life of light source	20000 h
RMS rated power	10 W
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	23 dB
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	375 mm
Width	458 mm
Height	228 mm
Weight	9300 g
Package depth	590 mm
Package width	350 mm
Package height	532 mm
Package weight	12.954 g
