Epson EH-TW5800 - Supported Resolutions

Appendix
79
Signal For-
mat
Resolution
(Dot)
V Sync
(Hz)
Dotclk
(MHz)
HDMI
RGB YCbCr
4:4:4 4:2:2 4:2:0
8
10, 12 8 10, 12 8 10, 12 8 10, 12
HDTV (1080p) 1920 1080 24 74.250
HDTV (1080p) 1920 1080 29.97 74.176
HDTV (1080p) 1920 1080 30 74.250
HDTV (1080p) 1920 1080 50 148.500
HDTV (1080p) 1920 1080 59.94 148.352
HDTV (1080p) 1920 1080 60 148.500
3D
Signal For-
mat
Resolution
(Dot)
V Sync
(Hz)
Dotclk
(MHz)
3D Format HDMI
RGB YCbCr
4:4:4 4:2:2
8
10, 12 8 10, 12 8 10, 12
HDTV (720p)
1280 720 60
148.500
Frame Pack-
ing
74.250 Side by Side
74.250 Top and Bot-
tom
HDTV (720p) 1280 720 59.94 148.500 Frame Pack-
ing
74.250
Side by Side
74.250 Top and Bot-
tom
HDTV (720p) 1280 720 50 148.500 Frame Pack-
ing
74.250 Side by Side
74.250 Top and Bot-
tom
HDTV (1080i) 1920 1080 60 148.500 Frame Pack-
ing
74.250 Side by Side
74.250 Top and Bot-
tom
HDTV (1080i) 1920 1080 59.94 148.500 Frame Pack-
ing
74.250 Side by Side
74.250 Top and Bot-
tom
